Topglass

Topglass® GC
LONG LASTING NATURAL ROOF LIGHTING-HIGH RESISTANCE AGAINST WEATHERING AND SOLAR DETERIORATION
Topglass GC is the top Product of all the Topglass natural lighting family of Products, utilizing an innovative manufacturing process developed by I-Cons Asia Co., Ltd. whereby Climatex Gel Coating 100 micron gelcoat exclusively developed for Topglass is applied to the weather surface of the sheeting. Having 100 microns thick coating offers exceptional resistance against corrosive atmospheres, and providing protection against solar deterioration that will result in glass fiber showing.


Key Benefits
– Heavy duty 100 micron* Climatex Gel Coated surface provides a longer life light transmission and prevent glass showing.
– Climatex Gel Coating surface, which is reactive thermo-set to provide high gloss surface.
– Topglass GC, which is manufactured to meet the requirements of AS 4256:3.2006 resist UV degradation and yellowing much longer than is commonly exerienced with general purpose grade translucent roofing products.
– Topglass GC can be supplied in a variety of pigments and can be supplied as Topglass GC SPF. This innovative gelcoat additive provides excellent UVA and UVB block and offers exceptional heat and light data

Applications
– Roof and wall lighting for commercial and industrial buildings.
– requiring long term natural lighting without early surface degradation.
– Educational facilities (Schools, Universities, Polytechnics) and childcare centers.
– Public outdoor areas requiring good UV protection.
Topglass Laboratory
1. Barcol Hardness (Barcol Impressor Model no.GYZJ.934)
2. Exposure Ultraviolet lamps M/C (Compile AS/NZS 2433)
3. Spectrophotometer (Model no. CM-3600A for measurement L,A,B)
4. Diffuse Light Tranmission M/C (AS/NZS 4257.4)
5. Impact Resistant M/C (Compile AS/NZS 4257.6)
6. QUV Accelerated Weathering Chamber UVB313 (ASTM G53)
7. Microscope Camera
Spacification
เรซิ่น (Raw Material)
ใช้เรซิ่นคุณภาพสูง และผสมสาร UV Absorber Plus (UVAS+) เป็นสารที่ผลิตด้วยนาโนเทคโนโลยี ช่วยซึมซับรังสี UV ป้องกันรังสี UV ไม่ให้ผ่านลงมาด้านล่างผิวแผ่นได้อย่างมีประสิทธิภาพ
ชั้นเคลือบบน (Top Coating)
EXO-SET 205 ชั้นเคลือบเจลคุณภาพสูงด้วยเทคโนโลยีการผลิตจากประเทศนิวซีแลนด์ มีความหนา 100 ไมครอน เพื่อการป้องกันรังสี UV อย่างมีประสิทธิภาพ
ใยแก้ว (Fiber Glass)
ใช้เส้นใยแก้วคุณภาพสูง เพื่อเพิ่มความแข็งแรงของแผ่นโปร่งแสงให้แผ่นมีอายุการใช้งานที่ยาวนาน ไม่กรอบแตกง่าย
ชั้นเคลือบล่าง (Bottom Coating)
Release film เนื่องจากไลน์ผลิตมีความยาวสูงกว่า 47m. ทำให้แผ่นที่ผ่านกระบวนการผลิตทำปฏิกิริยาสมบูรณ์แบบ จึงไม่จำเป็นต้องมีฟิล์มล่าง เพื่อป้องกัน เรซิ่นระเหิด
กระบวนการผลิต (Production Process)
CHP Technology Cumean Hydro Peroxide Activater. ระบบการผลิตที่ทันสมัยจาก ประเทศนิวซีแลนด์
ความหนา / น้ำหนัก (Thickness / Weight)
Thickness = 1.5 mm.
Weight = 2400 gsm.

Solar Energy Performance
Visble Light and Solar Tranmisson | ||
---|---|---|
Product | %Diffuse Light Transmission (AS/NZS 4257.4) Tolerance ±3 | %Solar Transmittance (ISO 9050) Tolerance ±3 |
Clear | 71% | 71% |
Ivory | 54% | 40% |
Cool White | 38% | 11% |
Solar Energy Performance | ||||
---|---|---|---|---|
Product | Shading Coefficient Tolerance ±0.02 | Solar Heat Gain Coefficient Tolerance ±0.02 | %Visible Light Transmittance Tolerance ±3 | %Diffuse Light Transmission Tolerance ±3 |
Cool White | 0.20 | 0.17 | 8.9 | 38 |
Color
Standards & Certifications

ISO 9001 : 2015

TIS 612 – 2549

AS/NZS 4256.3 : 2006

– ได้รับมาตรฐาน AS/ NZS 4256.3 :2006 Client BMP NO.535535 มาตรฐานจากออสเตรเลีย ที่ได้รับการยอมรับกว่า 90 ประเทศทั่วโลก
– ได้รับการรับรองคุณภาพการผลิต BSI Group จากประเทศจากออสเตรเลีย ซึ่งเป็นหน่วยงาน รับรองมาตรฐานผลิตภัณฑ์เป็นที่ยอมรับใน 150 ประเทศทั่วโลก
– ได้รับมาตรฐานอุตสาหกรรม มอก. 612-2549 ของประเทศไทย
